The Cylinder Head Washing machine is designed for cleaning of 3 cylinder, cylinder & 6 cylinders with greater load capacities for handling larger parts.

The Cylinder Head has to be kept on a trolley at the load / unload platform of the machine. When the “Cycle Start” button is pressed, the trolley moves inside the wash chamber & front door closes automatically. During operation the component inside the chamber on the rotary table rotates by High pressure pump thereby hot water alkaline solution is sprayed over the components.

After washing process has been completed in the same chamber Fresh Water Rinse & Hot Air blowing takes place one by one & component retracts to the Unloading station. The parts has to be unloaded as similar to the process of loading.

Process

Aqua based alkaline high pressure spray over the component
Re-circulation Rinse & fresh water rinse system
Cold & Hot Air Blow.
Online Fine Filtration system
Both side loading & Unloading option available.
Auto Detergent Dosing Unit
Auto water fill – ensure the system always has enough water

Standard Accessories

Wash & Rinse tank
Stainless steel construction for all wetted components.
On line & off line Filtration system – 5 to 150 micron bag filtration
PLC Controlled Electrical panel with HMI display
Stainless steel disc oil skimmer.
Oil separating systems
Sludge extraction systems
Fume exhaust / Mist collector systems
Tank & Booth Insulation
